SKU NO. | LOAD CAPACITY | HEIGHT LOWERED | BATTERY TYPE | BATTERY CAPACITY | TIRES TYPE | WT(LBS) |
A-4002 | 4,400 lbs | 220'' | Lithium-ion | 48V/450Ah | Solid | 8,470 lbs |
CAPACITY SHEET
Lifting height | Actal capacity |
below 118'' | 4,400 lbs |
118''-137'' | 3,740 lbs |
137''-157'' | 3,300 lbs |
157''-177'' | 2,750 lbs |
177''-196'' | 2,640 lbs |
196''-220'' | 1,650 lbs |
DIMENSIONS
- Overall Length: 122"
- Overall width: 44.5''
- Recommended Aisle Width: 130"
- Turning Radius : 65"
- Load center : 19.7"
MAST
- Mast Height Lowered: 97''
- Max.Lifting height: 220''
- Mast Height Raised: 262''
- Free Lifting height: 56''
- Mast Tilt Angle(forward/backward): 3° /6 °
FORKS
- Thickness: 1.6"
- Width: 4.7"
- Length: 42"
SIDESHIFTER
- Left and right reach distance: 4''
SPEED
- Travel Speed(laden/unladen): 8/8 mile/h
- Lifting Speed(laden/unladen): 9.8/16.5 inch/s
- Lowering Speed(laden/unladen):< 23.6 inch/s
MULTI-FUNCTION DISPLAY
Speed Mode
- H: High speed
- S: Standard speed
- E: Economic speed
Driving Direction
- N: Neutral status
- ↑: Forward
- ↓: Backward
BDI
- 1: Full battery
- 1/2: Half battery
- 0: Empty battery
- Working hour display
- Current speed display
FAULTY CODE(if have problem, it will show the faulty code to help to find the cause quickly)
CHARGING
- 6-8 hours service per charge with big power lithium battery capacity 48V/450AH.
- Only 3 hours charging time.
- Charger plugs into 3-phase industrial 220V power outlets.
- Charge the truck once a month even it's not in use.
FEATURES
- Gradeability(laden/unladen): 15%/20%
- Comfortable seat with safety belt and handrail.
- Excellent operator visibility.
- Small turning radius makes for better loading, unloading and stacking in the confined warehouses.
SPECIFICTIONS
- Not explosion proof.
- This truck is designed to be used on flat ground, avoiding uneven grounds with potholes or large ramp.
- Temperature range of working environment below 50˚F˜104˚F
Apollo Forklift provides 1 Year limited warranty upon the date of product’s receipt, easy-wearing parts and human damages are not covered by warranty. Our warranty obligation is to provide a replacement for a defective original part if the part is covered by the warranty.
1- Within 30 days of the receipt, if the product exists any quality problem, free replacement parts and professional remote technical guidance will be provided. In case our after-sale department determines the product needs to return for repair, all round-trip shipping costs will be borne by us."
2- Within 30 days-1 year of the receipt, if the product exists any quality problem, free replacement parts and professional remote technical guidance will be provided, if the product needs to return for repair as necessary, the customer needs to bear half of the shipping costs.
3- After 1 year of the receipt, if the product exists any quality problem, free technical guidance will be provided, however the customer needs to pay for the replacement parts, and if needs to return for repair, related maintenance costs as well as all round-trip shipping costs will be charged, which will be quoted in depends
Please note for spare parts orders, the warranty period is 3months, battery is 6months.
